ProSecure Unified Threat Management (UTM) Appliance Reference Manual
Firewall Protection 5-27
v1.0, January 2010
Configuring Other Firewall Features
You can configure attack checks, set session limits, and manage the Application Level Gateway
(ALG) for SIP sessions.
Attack Checks
The Attack Checks screen allows you to specify whether or not the UTM should be protected
against common attacks in the DMZ, LAN, and WAN networks. The various types of attack
checks are listed on the Attack Checks screen and defined in Table 5-4 on page 5-28.
To enable the appropriate attack checks for your network environment:
1. Select Network Security > Firewall from the menu. The Firewall submenu tabs appear.
Figure 5-15
