ProSecure Unified Threat Management (UTM) Appliance Reference Manual
Using the Setup Wizard to Provision the UTM in Your Network 2-11
v1.0, January 2010
Setup Wizard Step 2 of 10: WAN Settings
Enter the settings as explained in Table 2-2 on page 2-12, then click Next to go the following
screen.
DNS Proxy
Enable DNS Proxy This is optional. Select the Enable DNS Proxy radio button to enable the UTM
to provide a LAN IP address for DNS address name resolution. This setting is
enabled by default.
Note: When you deselect the Enable DNS Proxy radio button, the UTM still
services DNS requests that are sent to its LAN IP address unless you disable
DNS Proxy in the firewall settings (see “Attack Checks” on page 5-27).
Figure 2-8
Table 2-1. Setup Wizard Step 1: LAN Settings (continued)
Setting Description (or Subfield and Description)
