ProSecure Unified Threat Management (UTM) Appliance Reference Manual
A-4 Default Settings and Technical Specifications
v1.0, January 2010
Table A-4 shows the SSL VPN specifications for the UTM.
IPsec authentication types Local User database, RADIUS PAP, RADIUS CHAP
IPsec certificates supported CA digital certificate, Self digital certificate
Table A-4. UTM SSL VPN Specifications
Setting Specification
Network Management Web-based configuration and status monitoring
Number of concurrent users supported The number of supported dedicated SSL VPN tunnels depends on
the model (see NETGEAR’s marketing documentation at
http://prosecure.netgear.com).
SSL versions SSLv3, TLS1.0
SSL encryption algorithm DES, 3DES, ARC4, AES-128, AES-192, AES-256
SSL message integrity MD5, SHA-1, MAC-MD5/SHA-1, HMAC-MD5/SHA-1
SSL authentication types Local User database, RADIUS-PAP, RADIUS-CHAP,
RADIUS-MSCHAP, RADIUS-MSCHAPv2, WIKI-PAP,
WIKID-CHAP, MIAS-PAP, MIAS-CHAP, NT Domain
SSL certificates supported CA digital certificate, Self digital certificate
Note: For default e-mail and Web scan settings, see Table 6-1 on page 6-2.
Table A-3. UTM IPsec VPN Specifications (continued)
Setting Specification
